Modle E5
Modle E5
- ability:1500-2500 pcs/hour/single station
- Cardboard type:Corrugated cardboard cardboard
- Box type:: C1
- Box size:70*70*30mm-400*300*150mm
- delivery time:60 days
TECHNICAL DATA
Speed: 1500-2500 Trays/hour/one head.
Production running speed depends on box shapes, board dimensions and quality.
Electrical supply: 400 V – 50Hz 3 phases + N + G
Control voltage: 24 VDC
Working temperature: from 5°C to 35°C.
Installed power: 6.5KW
Air consumption: 6 Nl / cycles.
gWeiht: 1500 KG.
